Grout Volume Calculator – Estimate Grout Volume, Weight, and Bags

Last updated: 21 May 2025 | Author: Brij | Review By: Irshad

Share on :

Use our free Grout Volume Calculator to estimate how much grout you need based on tile size, joint width, tile thickness, and area. Get volume in cubic feet, weight in lbs, and bags required.

Tile Length:

Tile Width:

Tile Thickness:

Joint Width:

Area to be Tiled:

Grout Type:

Grout Calculation Results

Grout Volume:

cubic feet

Grout Weight:

pounds

Bags Required:

bags

What is Grout Volume?

Grout is the filler material used between tiles. Knowing how much grout is required helps reduce material waste and cost. This calculator estimates grout volume, weight, and the number of grout bags needed based on your tile and joint specifications.

Grout Volume Calculation Formulas

1. Joint Length Per Tile

We calculate the perimeter (joint lines) of one tile:

Formula:

$\text{Joint Length} = 2 \times (\text{Tile Length} + \text{Tile Width})$

2. Joint Area Per Tile

Now multiply the joint length by the joint width:

Formula:

$\text{Joint Area} = \text{Joint Length} \times \text{Joint Width}$

3. Tiles Per Square Foot

To find how many tiles fit in one square foot:

Formula:

$\text{Tiles per Sq.Ft} = \frac{144}{\text{Tile Length} \times \text{Tile Width}}$

4. Total Joint Volume (in³)

Total grout joint volume across the full tiled area:

Formula:

$\text{Total Volume (in}^3\text{)} = \text{Joint Area} \times \text{Tiles per Sq.Ft} \times \text{Area} \times \text{Tile Thickness}$

5. Convert to Cubic Feet

Convert cubic inches to cubic feet:

Formula:

$\text{Grout Volume (ft}^3\text{)} = \frac{\text{Total Volume (in}^3\text{)}}{1728}$

6. Estimate Grout Weight

Using approximate grout density:

Sanded: 12 lb/ft³
Unsanded: 10 lb/ft³
Epoxy: 14 lb/ft³

$\text{Grout Weight (lb)} = \text{Grout Volume} \times \text{Density}$

7. Estimate Number of Grout Bags

Assuming 1 bag = 25 lbs:

$\text{Bags Required} = \frac{\text{Grout Weight}}{25}$

Example Calculation

Let’s say:

Tile Length = 12 in
Tile Width = 12 in
Joint Width = 1/8 in
Tile Thickness = 0.5 in
Area = 100 sq.ft
Grout Type = Sanded (12 lb/ft³)

1. Joint Length:

$2 \times (12 + 12) = 48 \text{ in}$

2. Joint Area:

$48 \times \frac{1}{8} = 6 \text{ in}^2$

3. Tiles per Sq.Ft:

$\frac{144}{12 \times 12} = 1$

4. Total Volume (in³):

$6 \times 1 \times 100 \times 0.5 = 300 \text{ in}^3$

5. Grout Volume (ft³):

$\frac{300}{1728} \approx 0.1736 \text{ ft}^3$

6. Grout Weight:

$0.1736 \times 12 = 2.08 \text{ lb}$

7. Bags Required:

$\frac{2.08}{25} \approx 0.08 \Rightarrow \text{1 bag (minimum)}$

Conclusion

With this calculator, you can estimate:

Total grout volume in ft³
Total weight in lbs
Bags required

This tool helps you plan and purchase the right quantity of grout for your tiling project, reducing waste and cost.

Frequently Asked Questions (FAQs)

1. What is grout and why do I need to calculate its volume?

Grout is a material used to fill the gaps between tiles. Calculating the grout volume ensures you purchase the correct amount, minimizing waste and avoiding project delays.

2. What inputs are required for this grout volume calculator?

You need to enter the following values:

Tile Length
Tile Width
Tile Thickness
Joint Width
Area to be Tiled
Grout Type (Sanded, Unsanded, or Epoxy)
You can input dimensions in either inches or millimeters, and the area in square feet or square meters.

3. How is grout volume calculated?

The calculator estimates the volume of joints around each tile, multiplies it by the number of tiles in your area, and then converts it to cubic feet. The formula accounts for tile size, thickness, joint width, and total area.

4. What is the difference between sanded and unsanded grout?

Sanded grout is used for wider joints (more than 1/8") and has a higher density (approx. 12 lb/ft³).
Unsanded grout is used for joints 1/8" or less and is lighter (approx. 10 lb/ft³).
Epoxy grout is more durable and heavier (approx. 14 lb/ft³).

5. How accurate is the calculation?

The result is a close estimate for planning and budgeting purposes. Actual usage may vary slightly depending on tile layout, spacing, wastage, and surface conditions.

6. How many pounds are there in one grout bag?

Standard grout bags typically weigh 25 lbs. The calculator uses this as the basis to estimate the total number of bags needed.

7. Can I use this calculator for wall tiling too?

Yes! The calculator works for both floor and wall tiles, as long as you input accurate dimensions and area.

8. What if my tile dimensions are in millimeters?

No problem! Just choose mm from the unit dropdowns, and the calculator will automatically convert the values to inches for accurate calculations.

9. Can I round off the number of grout bags?

Yes, the calculator rounds up to the next whole number to ensure you have enough grout. It’s always better to have a little extra than to run short.
