Stair Baluster Spacing Calculator

Last updated: 31 Aug 2025 | Author: Brij | Review By: Irshad

Share on :

Use our Stair Baluster Spacing Calculator to find the number of balusters, slope spacing, and horizontal gaps for stair railings. Ensure safety and code compliance with ease.

Stair Tread Depth:

Stair Riser Height:

Stair Railing Length:

Baluster Width:

Maximum Allowed Gap:

Stair Angle (optional):

Stair Baluster Spacing Results

Number of Balusters Required:

Exact Spacing Along Railing:

inches

Horizontal Gap Between Balusters:

inches

Total Gap Coverage Along Stair:

inches

Calculated Stair Angle:

Stair Baluster Guidelines

Building Code:
Maximum 4-inch sphere must not pass through

Safety Standard:
Horizontal gap measured parallel to treads

Key Consideration: Horizontal gap is more restrictive than sloped gap on stairs

When installing stair railings, proper baluster spacing is crucial for both safety and appearance. Unlike flat railings, stair balusters must be calculated along the angled slope of the stairs, considering tread depth and riser height. Building codes usually require that the gap between balusters does not exceed 4 inches, ensuring safety for children and pets.

The Stair Baluster Spacing Calculator helps you determine the number of balusters needed, the exact spacing along the stair slope, and the horizontal gap between balusters.

Formula for Stair Angle

If stair angle is not provided, it can be calculated using:

$\text{Stair Angle} = \arctan\left(\frac{\text{Riser Height}}{\text{Tread Depth}}\right)$

Formula for Number of Balusters

The number of balusters along the stair railing is:

$\text{Number of Balusters} = \frac{\text{Stair Railing Length} + \text{Gap}}{\text{Baluster Width} + \text{Gap}}$

Formula for Spacing Along the Stair Railing

The spacing measured along the slope is:

$\text{Slope Spacing} = \frac{\text{Stair Railing Length} - (\text{Number of Balusters} \times \text{Baluster Width})}{\text{Number of Balusters} +1}$

Formula for Horizontal Gap Between Balusters

To check safety compliance, the horizontal gap (measured parallel to the stair tread) is:

$\text{Horizontal Gap} = \text{Slope Spacing} \times \cos(\text{Stair Angle})$

Formula for Total Gap Coverage

The total open space along the railing is:

$\text{Total Gap Coverage} = \text{Stair Railing Length} - (\text{Number of Balusters} \times \text{Baluster Width})$

Example Calculation

Let’s assume:

Tread Depth = 10 in
Riser Height = 7 in
Stair Railing Length = 120 in
Baluster Width = 2 in
Maximum Allowed Gap = 4 in

Step 1: Stair Angle

$\text{Stair Angle} = \arctan\left(\frac{7}{10}\right) \approx 34.99^\circ$

Step 2: Number of Balusters

$\text{Number of Balusters} = \frac{120 + 4}{2 + 4} = \frac{124}{6} \approx 20.67 \Rightarrow 21 \, \text{balusters}$

Step 3: Slope Spacing

$\text{Slope Spacing} = \frac{120 - (21 \times 2)}{21 + 1} = \frac{78}{22} = 3.54 \, \text{inches}$

Step 4: Horizontal Gap

$\text{Horizontal Gap} = 3.5 \times \cos(34.99^\circ) \approx 2.905 \, \text{inches}$

Step 5: Total Gap Coverage

$\text{Total Gap Coverage} = 120 - (21 \times 2) = 78 \, \text{inches}$

Conclusion

The Stair Baluster Spacing Calculator ensures your stair railing meets safety standards (less than 4 inches gap) while also maintaining visual symmetry. This helps homeowners, contractors, and DIY enthusiasts design safe and attractive stair railings.
