What is Bearing Pressure?
Bearing pressure is the pressure exerted by a structural foundation onto the underlying soil. It’s an essential calculation in geotechnical and structural engineering to ensure the soil can safely support the applied load from the structure above.
How to Calculate Bearing Pressure
To calculate bearing pressure, you only need two values:
- The total load acting on the foundation (P)
- The area of the footing (A)
Formula:
q=AP
Where:
- q = Bearing Pressure
- P = Load on the footing (kN or lbs)
- A = Area of the footing (m² or ft²)
Example Calculation
Let’s walk through an example to see how it works.
Given:
- Load (P) = 500 kN
- Footing Area (A) = 2.5 m²
Step-by-step Calculation:
q=2.5500=200kN/m2
Final Output:
- Bearing Pressure: 200 kN/m²
Why Use This Calculator?
- Quickly validate if your foundation design is safe
- Helps compare against allowable soil bearing capacity
- Saves time in structural or geotechnical planning
FAQs
Q 1. What is bearing pressure in foundation design?
Answer: Bearing pressure is the pressure exerted by the load of a structure on the soil beneath the foundation. It is calculated as the total load divided by the area of the footing and is a key factor in determining whether the soil can safely support the structure.
Q 2. What units are used for bearing pressure?
Answer: Bearing pressure is typically expressed in:
- kN/m² or N/mm² (Metric units)
- psf (pounds per square foot) or psi (pounds per square inch) in Imperial units
Q 3. What is the difference between bearing pressure and bearing capacity?
Answer:
- Bearing pressure is the actual pressure exerted by the structure on the soil.
- Bearing capacity is the maximum pressure that the soil can safely bear without failure.
Your design is safe when bearing pressure ≤ allowable bearing capacity.
Q 4What happens if bearing pressure exceeds soil bearing capacity?
Answer: If the bearing pressure exceeds the soil's allowable bearing capacity, the foundation may settle excessively or fail structurally, leading to cracks or even collapse of the structure. Proper calculation and soil testing are crucial.
