Estimate the grout needed for your block wall project. Get block count, grout volume, and shrinkage-adjusted totals with precision!

Wall Length:

Wall Height:

Block Size:

Grout Fill Type:

Mortar Joint Thickness:

inches

Grout Shrinkage (%):

Grout Calculation Results

Wall Area:

ft²

Grout Volume:

ft³

Total Grout (w/Shrinkage):

ft³

Blocks Needed:

blocks

80lb Bags Needed:

bags

Calculating grout for wall is important in construction because it helps builders accurately estimate the amount of grout (a type of concrete) needed to fill the hollow cores of concrete masonry units (CMUs) or blocks. Grout plays a crucial role in strengthening block walls, especially in load-bearing and reinforced masonry construction.

Formulas

1. Total Blocks Needed

To determine the number of blocks required, accounting for mortar joints:

$\text{Total Blocks} = \left\lceil \frac{\text{Wall Length (ft)}}{\text{Block Length + Mortar Joints (ft)}} \right\rceil \times \left\lceil \frac{\text{Wall Height (ft)}}{\text{Block Height + Mortar Joint (ft)}} \right\rceil$

2. Grout Volume per Block (Standard 8"x8"x16" CMU)

The industry-standard grout volume per fully grouted block:

Formula:

$\text{Grout per Block} = 0.0167 \text{ ft}^3$

3. Total Grout Volume (Without Shrinkage)

Calculates the total grout needed for the wall:

Formula:

$\text{Total Grout} = \text{Total Blocks} \times \text{Grout per Block} \times \text{Fill Factor}$

Fill Factor:

Full grout → 1
Partial grout (50%) → 0.5
Bond beam only → $\left\lceil \frac{\text{Wall Height (ft)}}{2} \right\rceil \times \text{Blocks per Course}$

4. Total Grout (With Shrinkage)

Accounts for material loss due to drying:

Formula:

$\text{Final Grout Volume} = \text{Total Grout} \times \left(1 + \frac{\text{Shrinkage \%}}{100}\right)$

Example Calculation

Scenario:

Wall Dimensions: 20 ft (length) × 8 ft (height)
Block Type: Standard 8"×8"×16" CMU
Mortar Joint: ⅜" (0.375")
Grout Fill: Full
Shrinkage: 10%

Step-by-Step Calculation:

Blocks Needed:

$\text{Blocks per Course} = \left\lceil \frac{20}{(16 + 0.75)/12} \right\rceil = 15$

$\text{Courses} = \left\lceil \frac{8}{(8 + 0.375)/12} \right\rceil = 12$

$\text{Total Blocks} = 15 \times 12 = 180$

Grout Volume:

$\text{Total Grout} = 180 \times 0.0167 = 3.006 \text{ ft}^3$

With Shrinkage:

$\text{Final Volume} = 3.006 \times 1.10 = 3.307 \text{ ft}^3$

Conclusion

This calculator ensures accurate grout estimation for block walls, whether for full grout, partial grout, or bond beams. Use the provided formulas to verify manual calculations or integrate them into construction planning tools.
