Sling Angle Calculator

Last updated: 12 Aug 2025 | Author: Brij | Review By: Irshad

Share on :

Calculate sling angles and tension forces quickly with our free Sling Angle Calculator. Perfect for riggers, crane operators, and engineers. Works with both metric and imperial units.

Height (Hook to Load):

Width (Between Attachments):

Load Weight (optional):

Sling Angle Results

Sling Angle:

degrees

Tension in Each Sling:

lbs

How the Sling Angle Calculator Works

This calculator determines the sling angle and tension force in lifting slings based on:

Height (from hook to load)
Width (distance between attachment points)
Optional Load Weight (for tension calculation)

Key Formulas Used

1. Sling Angle Calculation

The angle (θ) between the sling and the horizontal plane is calculated using the arctangent function:

$\theta = \tan^{-1}\left(\frac{\text{Height}}{\text{Width}/2}\right)$

2. Tension Force in Each Sling (If Load Weight Provided)

The tension (T) in each sling leg is calculated using:

$T = \frac{W}{2 \cdot \sin(\theta)}$

Where:

$W$ = Total load weight
$θ$ = Sling angle

Example Calculation

Scenario:

Height = 10 ft
Width = 8 ft
Load Weight = 2000 lbs

Step 1: Calculate Sling Angle

$\theta = \tan^{-1}\left(\frac{10}{4}\right) = \tan^{-1}(2.5) \approx 68.2°$

Step 2: Calculate Tension per Sling

$T = \frac{2000}{2 \cdot \sin(68.2°)} \approx \frac{2000}{1.856} \approx 1077 \text{ lbs}$

Result:

Sling Angle = 68.2°
Tension per Sling = 1077 lbs

Why This Calculator Matters

✅ Safety Compliance – Ensures sling angles stay within safe limits (typically 30°-60°).

✅ Prevents Overloading – Calculates exact tension to avoid sling failure.

✅ Works in Any Unit – Supports feet/meters and lbs/kg.
